The Epson SureColor F570 is a 24" dye-sublimation printer designed for fast, reliable printing on a variety of soft and rigid transfer media. With PrecisionCore MicroTFP technology, a 50-sheet auto-feed tray, built-in cutter, high-capacity ink bottles, and flexible connectivity, the F570 provides a compact, turnkey solution for dye-sublimation printing.
Key Features
- 24" dye-sublimation printing
- PrecisionCore MicroTFP 4-channel printhead
- Precision Droplet Control for detailed, clear output
- Nozzle Verification Technology
- Vibrant dye-sublimation ink for high color saturation and contrast
- Supports both roll and sheet media
- 50-sheet auto-feed tray
- Built-in high-speed rotary cutter
- High-capacity 140mL ink bottles with auto-stop filling
- 4.3" color touchscreen
- Compact desktop-friendly design
- Windows and Mac compatibility
- USB, Ethernet, Wi-Fi, and Wi-Fi Direct connectivity
- Designed for applications including awards, mugs, mousepads, and other dye-sublimation products
- Supports transfer paper for both soft and rigid materials
Compatibility & Requirements
- Compatible Media: Soft and rigid dye-sublimation transfer applications
- Maximum Paper Width: 24.4"
- Minimum Roll Width: 13"
- Minimum Sheet Width: 8.27"
- Media Thickness: Up to 8.6 mil
- Operating Systems: Windows and macOS
- Epson strongly recommends using genuine Epson ink for optimal print quality and performance.
Specifications
- Printing Technology: PrecisionCore MicroTFP 4-channel, drop-on-demand printhead
- Maximum Print Resolution: 2400 × 1200 dpi
- Minimum Ink Droplet Size: Variable Droplet Technology, up to three sizes per line
- Nozzle Configuration: 800 nozzles × 4 channels
- Ink Type: 140mL ink bottles
- Ink Colors: Black, Cyan, Magenta, Yellow
- Display: 4.3" touchscreen
- Maximum Printable Length: Limited by application, operating system, and driver/RIP
- Dimensions Without Stand: 38.2" × 20.7" × 9.6" / 970 × 505 × 230 mm
- Weight Without Stand: 84 lb / 38 kg
- Maximum Roll Diameter: 4.3"
- Media Core: 2" user-adjustable roll media adapters
- Sound Level: Approx. 50 dB(A) operating / 32 dB(A) sleep
- Rated Voltage: AC 110–240V
- Rated Frequency: 50–60 Hz
- Rated Current: 1.4A
- Power Consumption: Approx. 22W printing / 8W ready / 1.6W sleep / 0.2W power off
What's Included
- SureColor F570 Printer
- Start Here Poster
- User Guide
- AC Power Cable
Setup & Use
The SureColor F570 is designed for printing directly out of the box and includes dye-sublimation-optimized software with drivers for Windows and Mac. The printer supports roll and sheet media, with automatic sheet feeding and an internal rotary cutter for roll media.
