Vastex E-20 Series LED Entry level Screen Exposing Units 20" x 24"

by Vastex
SKU VT-E20-2024

The entry-level E-20 light box offers the same fast exposure times for producing high resolution half-tones and crisp detail as higher end models Equipped with two 15" (38 cm) VLB-15 LED light bars, it comes with an analog timer for automatic shut-off and a pressure plate to create tight glass-positive-screen contact. The glass exposure surface can be purchased separately from Vastex or supplied by the customer.

This tabletop unit can accommodate screens measuring up to 20 x 24 in. (51 x 61 cm) O.D., and can be combined with an optional S1-27 stand.

Note: For the E20-2024 base unit, GLASS SOLD SEPARATELY, (Vastex part number 04-08-09)



  1. LED bulbs for fast exposure time
  2. Expose 20" x 24" (51 x 61cm) max screen size
  3. Image Area: 12” x 16”(31 x 41 cm)
  4. Light Bars: (2) 15” (38 cm) bars
  5. Analog timer to automatically shut off lights
  6. Pressure pad to create good glass-positive-screen contact
  7. Weighs 45lbs (20.4kg) with glass and pressure plate
  8. Overall dimensions including pressure plate is 26.1x21.5x8.4" (67x55x22cm)
  9. Not upgradable


    • FAST: Exposes screens as fast as metal halide
    • QUALITY: Expose fine detail, half-tones
    • EFFICIENT: Operates at 20% of power required for metal halide
    • COMPACT: Slim design allows mounting on carts or drying cabinets
    • EXPOSE: Works with ANY emulsion
    • CONSISTENT: Pressure plate to create good glass-positive-screen contact
